Unimat
UniMAT
UN 331-1KF02-0AB0
SKU:
a19a797c5324
En Stock
SM 331 8 Analog expansion module 300 PLC equivalent of Siemens 300 PLC1). SM331 8AI ;2). Compatible with Siemens 6ES7331-1KF02-0AB0 ;3). Analog expansion input module ;4). Could connect with Siemens 300 CPU ;5). 3 year warranty ;
¿Necesitas más información?
Nuestro equipo técnico está listo para ayudarte con cualquier consulta.
Model SM3318AI Product Description 8AI;voltage/current/RTD temperature measurement modules; Resolution: 13bitsOptical isolation; high immunity; stable Power consumption @ Rate value / @ From backplane bus current consumption 90mA @ From L+ / @ Power loss 0.4W The power of transmitter @ Supply current / @ short-circuit protection / Number of analoginputs 8 Cable Length(Shielded) Max: 200m Input type and input range @ voltage 1~5V, 0~10V, ± 50mV± 500mV, ± 1V, ± 5V, ± 10V @ current(4wire) ± 20mA, 0~20mA, 4~20mA @ current(2wire) / @ tesistance 600Ω , 6KΩ @ thermocouple / @ RTD Pt100(-200C-850C) A/D resolution 13bits Basic conversion time(per channel) 66/55ms Interference frequency suppression 50/60Hz Tolerance(Over entire temperature range) @ Voltage ± 0.6% @ Current ± 0.6% @ resistance ± 0.6% @ temperature ± 1C Interrupts Diagnostic interrupt None Limit-value interrupt None Isolation tested for contact @ Between channels None @ Between channels and backplane bu Yes Front connector 40-pin Dimensions(W x H x D)(mm) 40× 125× 120 Order Number UN 331-1KF01-0AB0
No hay especificaciones técnicas disponibles.
